Conceptual Design for Experimental Main Loop with High Temperature Helium Gas
-
摘要: 依据聚变堆包层热工水力实验段的设计要求,并借鉴国内外氦气实验回路的设计和运行经验,对国际热核聚变实验堆(ITER)氦冷固态增殖剂实验包层模块(HCSB-TBM)高温氦气实验主回路进行了概念设计。主要给出了氦气实验主回路(HTHEL)的主要设计参数、回路系统构成及主要设备特点,并对主管道设计进行了应力校核。Abstract: Based on the design and running experiences on the helium experimental loops home and abroad,the preliminary conceptual design of the main helium loop,HTHEL,is completed according to the design requirements on TBM experimental section.The main design parameters,the system constitutes and main component characteristics for this loop are presented and the stress check is conducted for the design of main pipeline.
-
Key words:
- TBM /
- Main loop /
- Conceptual design /
- Pipeline
-
