Modeling of Reactor Power Control System and Closed Loop Verification
-
摘要: 基于MATLAB/SIMULINK仿真软件,对岭澳一期核电站功率控制系统进行建模。通过与RELAP5完成的核电厂主回路热工水力模型相连接,对该控制系统模型进行了闭环瞬态工况测试。将计算机仿真结果与电厂试验曲线进行了比较,两者非常吻合,定性和定量地验证了本控制模型和热工模型的正确性。
-
关键词:
- 反应堆 /
- 功率控制 /
- 闭环验证 /
- RELAP5 /
- MATLAB/SIMULINK
Abstract: The model of nuclear power control system of Ling’ao NPP based on MATLAB/SIMULINK was established. Closed loop test was realized by coupling with the thermal-hydraulic model of primary loop which is based on RELAP5. The comparison of simulated result with test result from NPP shows a good coordination, and the correctness of the model was proved qualitatively and quantitatively.-
Key words:
- Reactor /
- Nuclear power control /
- Closed loop verification /
- RELAP5 /
- MATLAB/SIMULINK
-
