Application of Leak-Before-Break (LBB) Analysis Method for Liquid Metal Cooled Fast Breeder Reactors(LMFBR) in Pipeline Analysis
-
摘要: 采用破前漏(LBB)分析方法,对中国实验快堆余热排放系统中间回路进行断裂力学分析。假设在其受力最严重的管段,反应堆运行前已存在一个贯穿裂纹,根据系统寿期内的运行工况,运用J积分撕裂模量汇交方法,求出在综合最恶劣工况(即合成出包络工况)下裂纹的临界长度;通过Paris公式求出该裂纹在交变载荷作用下的稳定扩展量;利用CASTEM2000程序建立力学模型,分别求出包络工况下寿期末裂纹和临界裂纹的张开面积。结果证明,该管道在其寿期内可能出现的最大裂纹张开面积小于(DT)/4(D为管道直径,T为管壁厚)。Abstract: Based on the Leak-Before-Break (LBB) Analysis Method, this paper performs a fracture mechanics analysis on the intermediate loop of the decay heat removal system in China Experimental Fast Reactor(CEFR). Assuming that before the operation of the reactor a throughwall defect had existed where the loads were most serious, according to J-integral tearing modulus inter-section method, the critical length of crack in the worst condition (namely synthesized enveloped operation conditions) was obtained. With Paris formula, the stability expansion of the crack was calculated under alternating loads. The open area of the critical crack as well as that of the life-end crack were obtained by a mechanical model established by CASTEM2000 code. It is proved that the biggest crack open area of the tube is less than DT/4 (D means pipeline diameter,and T tube wall thickness) at the end of its life.
-
