Seal Analysis Technology for Reactor Pressure Vessel
-
摘要: 反应堆压力容器内的冷却剂具有压力高、温度高、放射性剂量高等主要特点,保证压力容器的密封性能对整个核反应堆系统安全运行至关重要。本文针对密封结构的密封性能分析方法与技术进行了研究,包括螺栓预紧、弹塑性接触、热与结构的耦合分析技术等,完成了反应堆压力容器的三维弹塑性密封分析技术研究,全面地考虑了结构承受的各种载荷,实现了结构接触面之间有摩擦的弹塑性接触和接触传热问题的模拟。该分析方法弥补了专用密封分析程序适用范围狭小以及分析过程的烦琐等不足,较目前通用的二维密封分析技术考虑的因素更加全面。该技术已成功应用于工程设计中的压力容器设计与分析。Abstract: There is the coolant with radiation, high temperature and high pressure in the reactor pressure vessel(RPV). It is closely correlated to RPV sealing capability whether the whole nuclear system work well or not. The aim of this paper is to study the seal analysis method and technology, such as the pre-tensioning of the bolt, elastoplastic contact and coupled technology of thermal and structure. The 3D elastoplastic seal analysis method really and generally consider the loads and model the contact problem with friction between the contact plates. This method is easier than the specialized seal program and used widely.And it is more really than the 2D seal analysis method. This 3D elastoplastic seal analysis method has been successfully used in the design and analysis of RPV.
-
Key words:
- Reactor pressure vessel /
- Sealing capability /
- Analysis method
-
