自然循环蒸汽发生器倒U型管内的倒流计算

留言板

尊敬的读者、作者、审稿人, 关于本刊的投稿、审稿、编辑和出版的任何问题, 您可以本页添加留言。我们将尽快给您答复。谢谢您的支持!

姓名

邮箱

手机号码

标题

留言内容

验证码

基金项目:

国家自然科学基金项目(50676051)

空泡物理和自然循环重点实验室基金资助项目

Calculation of Reverse Flow in Inverted U-Tubes of Steam Generator during Natural Circulation

1. Department of Thermal Engineering, Key Laboratory for Thermal Science and Power Engineering of Ministry of Education, Tsinghua University, Beijing, 100084, China;
2. National Key Laboratory of Bubble Physics and Natural Circulation, Nuclear Power Institute of China, Chengdu, 610041, China

摘要: 采用同时表示正流和倒流的全水动力特性曲线分析了自然循环压水堆一回路系统蒸汽发生器倒U型管内发生倒流的机理。针对蒸汽发生器内倒U型管数量巨大问题,提出了一种集总-分布参数模型。该模型用于计算实际自然循环蒸汽发生器倒U型管内的倒流时,具有计算快捷且精度高的优点。利用该模型对自然循环蒸汽发生器并联倒U型管内的正、倒流进行计算,并将计算结果与所有倒U型管逐根进行正、倒流计算的结果进行比较,结果十分接近,验证了本文模型的可靠性。
- 蒸汽发生器 /
- 自然循环 /
- 倒流 /
- 计算模型
Abstract: The mechanism of reverse flow in inverted U-tubes of steam generators of pressurized water reactors during natural circulation is analyzed by using the full range characteristic curve of parallel U-tubes.A lumped?distributed model to calculate the reverse flow occurred in inverted U-tubes of real steam genera-a well agreement with that predicted by the model in which normal or reverse flow in each individual U-tube is analyzed,which verifies the reliability of the model developed in this paper.
- Steam generator /
- Natural circulation /
- Reverse flow /
- Calculation model
