Welding Defect Extraction of X-Ray Image Based on Adaptive Morphological Filtering Operator
-
摘要: 将数学形态学滤波算法应用于X射线焊接图像的缺陷提取,关键在于确定结构元素大小。本文提出一种自适应数学形态学滤波算法,首先对垂直于焊接图像的扫描线进行分水岭变换来确定结构元素尺寸大小,结构元素能随缺陷尺寸大小自动调整,然后应用数学形态学开操作得到图像背景,原始图像减去背景图像得到滤波结果。将本方法用于焊接缺陷边缘的提取,取得了好的效果。Abstract: When mathematic morphological filtering methods are applied on the welding defect extraction of X-ray image, the key is the size of structural elements. An adaptive morphological filtering is proposed in this paper:Firstly the sizeof structural elements is chosen on the basis of the result of watershed transformation on scanning beams which is vertical to the welding image, and the size can be adaptively adjusted according to the size of the welding defect. Then the mathematic morphological opening operator is applied on the image to subtract the result from the original image, and the filtering results are reached finally. This method was applied in the extraction of welding defect edge to obtain satisfactory results.
-
