Study on Virtual Simulation Technology for Operation and Control of PWR
-
摘要: 讨论了利用MultiGen Creator软件工具集实现对压水堆进行建模的方法,建立了压水堆运行控制的虚似仿真所需的三维模型。通过对压水堆数学仿真的研究,建立了基于MFC和Vega平台的压水堆数学仿真模型。针对稳压器讨论了虚拟效果仿真的实现方法,并通过VC++编程完成对各部分的连接,实现了压水堆的虚拟仿真。
-
关键词:
- 压水堆 /
- 稳压器 /
- Vega/MultiGen平台 /
- 虚拟仿真技术
Abstract: The way to build graphical models of PWR with MultiGen Creator is discussed,and the three-dimensional model used in the virtual simulation is built.The mathematical simulation model for PWR based on the platform of MFC and Vega is built through the analysis of the mathematical simulation of PWR. The way to perform the virtual effect is introduced associating with the Pressurizer.And,all above parts are connected in one with VC++ to perform the whole virtual simulation of PWR.-
Key words:
- PWR /
- Pressurizer /
- Platform of Vega/MultiGen /
- Virtual simulation technology
-
