Online Monitoring System of Active Magnetic Bearings for HTR-10GT
-
摘要: 基于虚拟仪器技术,实现了对电磁轴承系统运行状态的实时监测,并在此基础上对系统状态信号进行多种在线、离线数据分析,提取出系统运行状态的特征并判断系统工作是否正常。实验证明,初步建立的监测系统功能完善,有很好的可扩充性,是一个功能强大的信号监测和分析平台。Abstract: Based on virtual instruments (Ⅵ) technology, we have successfully carded out the real-time monitoring of the operation status of the AMB system, and then made some online and offline data analyses on the status signal to draw out the characteristics of the system operation status to judge whether the system behaves normally or not. The test shows that this preliminary monitoring system is a powerful signal monitoring and analyzing platform which has integrated function and good expansibility in the experiment of a small flexible rotor AMB test rig (AMB-P)’s passing the first BCS.
-
Key words:
- HTR /
- HTR-10GT /
- Active Magnetic Bearings(AMBs) /
- Virtual Instruments(Ⅵ) /
- Online Monitoring System
-
