Numerical Simulation of Interface Movement in Gas-Liquid Two-Phase Flows with Level Set Method
-
摘要: 用数值模拟方法来研究气-液两相流动与传热现象是当今多相流领域的一个热门课题。由于两相流固有的复杂性,气-液两相流界面迁移现象的数值模拟一直是两相流研究中的一大难点。本文介绍了捕捉气-液两相流相界面运动的水平集方法(LevelSet)及其研究进展,介绍了求解LevelSet输运方程的3种方法,即一般差分格式、Superbee-TVD格式和Runge-Kutta法-5阶WENO组合格式。结合主流场的求解,分别用这3种方法对4种典型相界面在5种流场中的迁移特性进行了模拟计算,并对计算结果进行了比较和分析。结果表明,Runge-Kutta法-5阶WENO组合格式求解LevelSet输运方程的效果最好,在以后的计算中将主要采用这种组合格式来进行气-液相界面输运方程的求解。
-
关键词:
- 运动界面 /
- Level Set方法 /
- 气-液两相流 /
- 5阶WENO格式 /
- Superbee-TVD格式
Abstract: Numerical simulation of gas-liquid two-phase flow and heat transfer has been an attractive work for a quite long time, but still remains as a knotty difficulty due to the inherent complexities of the gas-liquid two-phase flow resulted from the existence of moving interfaces with topology changes. This paper reports the effort and the latest advances that have been made by the author and his colaborators, with special emphasis on the methods for computing solutions to the advection equation of the Level set function, which is utilized to capture the moving interfaces in gas-liquid two-phase flows. Three different schemes, i.e. the simple finite difference scheme, the Superbee-TVD scheme and the 5-order WENO scheme in combination with the Runge-Kutta method are respectively applied to solve the advection equation of the Level Set. A numerical procedure based on the well-verified SIMPLER method is employed to numerically calculate the momentum equations of the two-phase flow. The above–mentioned three schemes are employed to simulate the movement of four typical interfaces under 5 typical flowing conditions. Analysis of the numerical results shows that the 5-order WENO scheme and the Superbee-TVD scheme are much better than the simple finite difference scheme, and the 5-order WENO scheme is the best to compute solutions to the advection equation of the Level Set. The 5-order WENO scheme will be employed as the main scheme to get solutions to the advection equations of the Level Set when gas-liquid two-phase flows are numerically studied in the future.-
Key words:
- Level set method /
- Gas-liquid two-phase flow /
- 5-WENO scheme /
- Superbee-TVD scheme /
-
