CENTER工程反应堆保护系统定期试验方案设计
doi: 10.13832/j.jnpe.2021.01.0080
Design of Periodic Test for Reactor Protection System of CENTER
-
摘要: CENTER工程反应堆保护系统采用了中国核动力研究设计院自主研发的“龙鳞”平台。根据GB/T 5204和IEEE 338的设计要求，本文基于定期试验的设计准则，采用分段试验和相互交迭的设计思路，同时结合平台自身的特点对CENTER工程反应堆保护系统的定期试验总体方案进行了介绍，重点描述了输入通道试验（T1试验）、系统逻辑功能试验（T2试验）、输出通道及相关驱动器试验（T3试验）和响应时间试验的试验方案及其工作原理，可作为其他工程定期试验方案设计的参考。Abstract: Reactor protection system of CENTER is based on NASPIC platform developed by NPIC. According to the requirement of GB/T 5204 and IEEE 338, based on the design criterion of periodic test, this paper introduces the overall scheme of periodic test for reactor protection system based on the principle of subsection and overlap as well as the characteristics of the NASPIC platform itself. T1 test, T2 test, T3 test, response time test and their principle are mainly described. This design can be referenced by other reactors.
-
Key words:
- CENTER /
- Periodic test /
- Reactor protection system
-
