HCF三维精细化燃耗特性分析

段倩妮; 汪洋; 李伟; 武俊梅

doi:10.13832/j.jnpe.2024.070038

HCF三维精细化燃耗特性分析

doi: 10.13832/j.jnpe.2024.070038

段倩妮^1,,
汪洋²,
李伟^1, ,,
武俊梅¹

1.
西安交通大学复杂服役环境重大装备结构强度与寿命全国重点实验室，西安，710049
2.
中广核研究院有限公司，广东深圳，518031

基金项目: 西安交通大学青年拔尖人才计划 (LX6J022)

详细信息

作者简介:
段倩妮（1995—），女，博士研究生，现主要从事核燃料研究工作，E-mail: dqn413@stu.xjtu.edu.cn

通讯作者:
李　伟，Email: waylee@xjtu.edu.cn

中图分类号: TL277
计量
- 文章访问数: 25
- HTML全文浏览量: 12
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2024-07-14
- 修回日期: 2024-09-04
- 刊出日期: 2025-08-15

HCF Three-dimensional Refined Burnup Characteristics Analysis

Duan Qianni^1
,,
Wang Yang²,
Li Wei^{1
, ,},
Wu Junmei¹

1.
State Key Laboratory for Strength and Vibration of Mechanical Structures School of Aerospace, Xi’an Jiaotong University, Xi’an, 710049, China
2.
China Nuclear Power Technology Research Institute Co., Ltd., Shenzhen, Guandong, 518031, China

摘要

摘要: 几何形状复杂的螺旋十字燃料（HCF）对燃耗特性研究提出了更高的挑战。传统的同心圆圈式燃耗区域划分方法无法准确地模拟HCF复杂的几何引起的燃料各位置燃耗不同的问题，缺乏相应的三维精细化数值分析方法预测燃耗特性。本文针对HCF提出六面体燃耗区域划分及计算机辅助设计（CAD）几何建模方法，分别以HCF的薄片、最小扭转单元、单根燃料为研究对象，实现三维精细化的燃耗计算，获得不同燃耗下变量分布及²³⁵U、 ²³⁸U、²³⁹Pu典型核素在凹、凸处的核子密度及核反应率。结果表明， HCF径向一周快中子通量密度、热中子通量密度、功率密度分布表现出极大的不均匀性，且随着燃料的消耗，其周向不均匀性增强，凸处燃耗较凹处深15.92 MW·d/kg。轴向扭转对燃料凸处物理变量的影响大于凹处。三维精细化的燃耗特性分析可为高保真的HCF中子物理和热工水力、力学等耦合计算提供基础。
- 螺旋十字燃料（HCF） /
- 燃耗计算 /
- 燃耗区域划分 /
- 功率密度
Abstract: Helical cruciform fuel (HCF) has a complex geometry, which poses a higher challenge to the study of burnup characteristics. The traditional concentric circle burnup region division method could not accurately simulate the different burnup at different positions caused by the complex geometry of HCF in the burnup, and lack corresponding three-dimensional refined numerical analysis method to predict the burnup characteristics. In this paper, a hexahedral burnup region division and Computer-Aided Design (CAD) geometric modeling method are proposed for HCF. By taking the slice, minimum twist unit and single fuel of HCF as the research object, three-dimensional burnup calculation are realized, and variable distribution under different burnups, nuclear density and nuclear reaction rate of typical nuclides ²³⁵U, ²³⁸U and ²³⁹Pu at concave and convex position are obtained. The results show that the fast neutron flux, thermal neutron flux and power density distribution of radial circumferential HCF show great non-uniformity. The circumferential non-uniformity increases with the depletion of fuel, the burnup in the convex position is 15.92 MW·d/kg deeper than that in the concave. The influence of axial twist on the physical variables of the convex position of fuel is greater than that of the concave position. Three-dimensional refined analysis of burnup characteristics provides a basis for high-fidelity coupling calculation of neutronic physics, thermal-hydraulics and mechanics of HCF.
- HCF /
- Burnup calculation /
- Burnup region division /
- Power density

HTML全文

图 1 创新型燃料设计示意图

Figure 1. Schematic Diagram of Innovative Fuel Design

下载: 全尺寸图片幻灯片

图 2 HCF几何示意图

Figure 2. Geometry Diagram of HCF

下载: 全尺寸图片幻灯片

图 3 HCF不同燃耗区域示意图

Figure 3. Schematic Diagram of Burnup Region Division of HCF

下载: 全尺寸图片幻灯片

图 4 HCF薄片燃耗期k_eff曲线图

Figure 4. Curve Diagram of k_eff during Burnup of HCF Slice

下载: 全尺寸图片幻灯片

图 5 不同燃耗步 HCF 截面功率密度分布示意图

Figure 5. Schematic Diagram of Cross-Section Power Density Distribution of HCF Slice in Different Burnup Steps

下载: 全尺寸图片幻灯片

图 6 不同燃耗步凹凸处核子密度曲线图

Figure 6. Curve Diagram of Nuclide Isotope Density at Concave and Convex Position in Different Burnup Steps

下载: 全尺寸图片幻灯片

图 7 不同燃耗步凹凸处核反应率曲线图

Figure 7. Curve Diagram of Nuclear Reaction Rate at Concave and Convex Position in Different Burnup Steps

下载: 全尺寸图片幻灯片

图 8 最小扭转单元快中子通量密度分布

Figure 8. Fast Neutron Flux Distribution of Minimum Twist Unit

下载: 全尺寸图片幻灯片

图 9 最小扭转单元热中子通量密度分布

Figure 9. Thermal Neutron Flux Distribution of Minimum Twist Unit

下载: 全尺寸图片幻灯片

图 10 最小扭转单元功率密度分布

Figure 10. Power Density Distribution of Minimum Twist Unit

下载: 全尺寸图片幻灯片

图 11 最小扭转单元HCF凸处及凹处燃耗初期及700 d 36 h后轴向功率密度

Figure 11. Axial Power Density at the Initial and after 700d 36h at Concave and Convex Position of HCF in Minimum Twist Unit

下载: 全尺寸图片幻灯片

图 12 单根HCF功率密度分布

Figure 12. Power Density Distribution of Single HCF

下载: 全尺寸图片幻灯片

表 1 燃料元件各区域核素成分及材料密度

Table 1. Nuclide Composition and Material Density in Each Region of Fuel Element

区域	核素	密度/（g·cm⁻³）
方形毒物区域	⁹⁰Zr,⁹¹Zr,⁹²Zr,⁹⁴Zr,⁹⁶Zr,¹⁵⁷Gd,⁹³Nb	6.5075
燃料棒	⁹⁰Zr,⁹¹Zr,⁹²Zr,⁹⁴Zr,⁹⁶Zr,²³⁵U,²³⁸U,²⁴¹Am,²²⁸Th,²²⁹Th, ²³⁹Th,²³²Th,²³⁵Np,²³⁶Np,²³⁷Np,²⁵²Cf	9.7012
包壳	⁹⁰Zr,⁹¹Zr,⁹²Zr,⁹⁴Zr,⁹⁶Zr,¹¹⁸Sn	6.4987
冷却剂	¹H,¹⁶O	0.7172

下载: 导出CSV

表 2 不同燃耗步HCF薄片最外侧周向平均功率密度q

Table 2. Outer Circumferential Average Power Density Distribution for the HCF Slice in Different Burnup Steps

燃耗时间	凸处q/(W·cm⁻³)	凹处q/(W·cm⁻³)
0 h	827	734
6 h	815	726
36 h	821	728
100 d 36 h	828	732
700 d 36 h	881	758

下载: 导出CSV

参考文献(16)

[1]	SHAH M D, GODDARD B, LLOYD C, et al. Investigating material attractiveness for an innovative metallic fuel design[J]. Nuclear Engineering and Design, 2020, 357: 110385. doi: 10.1016/j.nucengdes.2019.110385
[2]	HARDY M M. Geometric transformation for double helical wire rods[D]. Oahu: University of Hawaii, 2004.
[3]	BRITT T, GODDARD B, SHAH M. Innovative fuel design to improve proliferation resistance[J]. Journal of Nuclear Materials Management, 2019, 47(3): 5-8.
[4]	谢仲生. 核反应堆物理分析[M]. 北京: 原子能出版社,1981: 169-190.
[5]	SHIRVAN K, KAZIMI M S. Nuclear design of helical cruciform fuel rods[C]//Conference on Advances in Reactor Physics - Linking Research, Industry, and Education. Knoxville: American Nuclear Society, Inc. , 2012.
[6]	SILVA R H M, DE SOUZA W F, DA SILVA C A M, et al. Neutronic and thermal hydraulic analysis of a PWR fuel assembly using uranium mononitride[J]. Annals of Nuclear Energy, 2023, 194: 110071. doi: 10.1016/j.anucene.2023.110071
[7]	AKTER Y, SAHADATH M H, REZA F. Assessment of the burnup characteristics of UO₂ and MOX fuel in the mixed solid and annular rod configuration[J]. Nuclear Engineering and Design, 2021, 381: 111339. doi: 10.1016/j.nucengdes.2021.111339
[8]	SAENZ B L, JEVREMOVIC T. Burn-cycle-dependent spatial distribution of nuclear fuel actinides and fission products based on the AGENT code[J]. Annals of Nuclear Energy, 2021, 160: 108390. doi: 10.1016/j.anucene.2021.108390
[9]	KIM K M, CHOI N, LEE H G, et al. Practical methods for GPU-based whole-core Monte Carlo depletion calculation[J]. Nuclear Engineering and Technology, 2023, 55(7): 2516-2533. doi: 10.1016/j.net.2023.04.021
[10]	CLARNO K T, PHILIP B, COCHRAN W K, et al. The AMP (Advanced MultiPhysics) Nuclear Fuel Performance code[J]. Nuclear Engineering and Design, 2012, 252: 108-120. doi: 10.1016/j.nucengdes.2012.07.018
[11]	EBIWONJUMI B, LEE H, KIM W, et al. Validation of nuclide depletion capabilities in Monte Carlo code MCS[J]. Nuclear Engineering and Technology, 2020, 52(9): 1907-1916. doi: 10.1016/j.net.2020.02.017
[12]	ISOTALO A, SAHLBERG V. Comparison of neutronics-depletion coupling schemes for burnup calculations[J]. Nuclear Science and Engineering, 2015, 179(4): 434-459. doi: 10.13182/NSE14-35
[13]	GOORLEY T, JAMES M, BOOTH T, et al. Initial MCNP6 release overview[J]. Nuclear Technology, 2012, 180(3): 298-315. doi: 10.13182/NT11-135
[14]	ROMANO P K, HORELIK N E, HERMAN B R, et al. OpenMC: a state-of-the-art Monte Carlo code for research and development[J]. Annals of Nuclear Energy, 2015, 82: 90-97. doi: 10.1016/j.anucene.2014.07.048
[15]	LEPPÄNEN J, PUSA M, VIITANEN T, et al. The Serpent Monte Carlo code: status, development and applications in 2013[J]. Annals of Nuclear Energy, 2015, 82: 142-150.
[16]	ZHENG M Y, TIAN W X, WEI H Y, et al. Development of a MCNP–ORIGEN burn-up calculation code system and its accuracy assessment[J]. Annals of Nuclear Energy, 2014, 63: 491-498. doi: 10.1016/j.anucene.2013.08.020
